EL-04 / EL-05 / EL-06

Vehicular Access Control - Arm Barriers

Access Control Arm Barriers are fast and reliable, and used as a standalone access control solution or combined and syncronized with other barries, such as Bollards or Road Blockers.

With boom lengths that extend up to 8 meters, ELGO Team's electric arm barriers cover a multitude of access control applications, these security barriers are a combination of cutting-edge technology and crisp design. With a built-in soft start and stop controls, the electric arm barriers are efficient and resistant to mechanical wear and tear. The EL-04 extends up to 4 meters (13 ft), the EL-05 extends up to 6 meters (20 ft) and the EL-06 extends up to 8 meters (26 ft). These top-range security products come with an all-weather housing, adjustable dual direction operating speed.

Product
EL-04
EL-05
EL-06
Operation
Electrical
Electrical
Electrical
Arm Length (up to)
4m/13ft.
6m/20ft.
8m/26ft.
Arm Type
76 diameter/ Rectangular
76 diameter/ Rectangular
Aluminum double arm
40x80cm/ 15.6"x31.5"
40x80cm/ 15.6"x31.5"
Speed
3sec
6sec
6sec
Motor
0.75hp
0.75hp
0.75hp
Voltage
240v/110v
240v/110v
240v/110v
Controller
PLC
PLC
PLC
Cycles per Hour
240
170
120
MCBF
5M
5M
5M
IP Rating
IP55
IP55
IP55
