BLG-02-F
FIXED BOLLARD (M30/K4)
BLG-02-F (Fixed) M30/K4 crash test certified bollard is one of ELGO Team's solutions for permanent Urban Vehicular Access Control (pedestrian security) and high-security applications . This BLG-02-F measures 700mm (27.5”) in height and 219mm (8.6”) in diameter (also available in a 1,000mm / 39" option).
This bollards also comes with optional LED lights for maximum visibility. An excavation depth of 1,400mm (55”) is required when installing the BLG-02-F bollard. This product has been rigorously tested, based on ASTM M30/K4 standards, meaning that it can stop a vehicle weighing 6.8 tons driving at 48kph (30mph). Atop its outstanding features, the BLG-02-F also boasts an elegant design and look which makes it resonate with the aesthetics of different environment.
OR
Product | BLG-02-F |
|---|---|
Height (H) | 700mm/27.5" or 1,000mm/39" |
Foundation Depth | 700mm /27.5" to 1200mm /47" |
Sleeve Depth (I) | 700mm /27.5" to 1200mm /47" |
Internal Overlap (O) | 300mm/ 11.8" |
Diameter (D) | 220mm/ 8.7" |
Crash Rating | ASTM F2656 07-M30 Standards P1-Zero penetration
6.8 ton @65kph/ 13,600lbs @30mph |
Finish | Zinc/Paint/ Stainless/Polyurea |
Options | Heating/ Led Light |
