BLG-05-F
FIXED BOLLARD (M50/K12)
BLG-05-F (Fixed) M50/K12 crash test certified bollard is one of ELGO Team's solutions for permanent Urban Vehicular Access Control (pedestrian security) and high-security applications . This BLG-05-F measures 900mm (35”) to 1000mm (39") in height and 270mm (11”) in diameter.
This bollards also comes with optional LED lights for maximum visibility. An excavation depth of 1,850mm (72”) is required when installing the BLG-05-F bollard. This product has been rigorously tested, based on ASTM M50/K12 standards, meaning that it can stop a vehicle weighing 6.8 tons driving at 80kph (50mph). Atop its outstanding features, the BLG-05-F also boasts an elegant design and look which makes it resonate with the aesthetics of different environment.
OR
Product | BLG-05-F |
|---|---|
Height (H) | 900 mm/ 35" to 1000 mm/ 39 " |
Foundation Depth | 700mm /27.5" to 1850 mm/ 73" |
Sleeve Depth (I) | 700mm /27.5" to 1850 mm/ 73" |
Internal Overlap (O) | 700mm/ 27.5" |
Diameter (D) | 270 mm/ 11" |
Crash Rating | ASTM F2656 07-M50 Standards P1-Zero penetration
6.8 ton @80kph/ 13,600lbs @50mph |
Finish | Zinc/ Paint/ Stainless/ Polyurea |
Options | Heating/ Led Light |
