BLG-04-F

FIXED BOLLARD (M40/K8)

BLG-04-F (Fixed) M40/K8 crash test certified bollard is one of ELGO Team's f solutions for permanent Urban Vehicular Access Control (pedestrian security) and high-security applications . This BLG-04-F measures 750mm (29.5”) in height and 270mm (11”) in diameter.

This bollards also comes with optional LED lights for maximum visibility. An excavation depth of 1,750mm (69”) is required when installing the BLG-04-F bollard. This product has been rigorously tested, based on ASTM M40/K8 standards, meaning that it can stop a vehicle weighing 6.8 tons driving at 65kph (40mph). Atop its outstanding features, the BLG-04-F also boasts an elegant design and look which makes it resonate with the aesthetics of different environment.

OR

Product
BLG-04-F
Options
Heating/ Led Light
Finish
Zinc/ Paint/ Stainless/ Polyurea
Crash Rating
ASTM F2656 07-M40 Standards P1-Zero penetration 6.8 ton/ 65kph/ 13,600lbs/40mph
Diameter (D)
270 mm/ 11"
Internal Overlap (O)
600mm/ 16"
Sleeve Depth (I)
700mm /27.5" to 1600mm /63"
Foundation Depth
700mm /27.5" to 1600mm /63"
Height (H)
750mm/ 27.5"
