BLG-04-SA

SEMI-AUTOMATIC RETRACTABLE BOLLARD (M40/K8)

The BLG-04-SA (Semi Automatic) is a manually tactivated bollard with a K8/M40 crash rating. Bollard is operated by an hydraulic piston. The bollard is pumped to an upper position using a handle, and retracted using a key, by sheer gravity. Alongside its affordable price (purchase and operational price) and reliability, make an ideal solution for Urban Vehicular Access Control (pedestrian security) and high-security applications in places where the bollards are less frequently operated (for example, seasonlly closed pedestrian streets). The BLG-04-SA does not require any underground cabling is required which reduces installations costs and operational costs. BLG-04-SA measures 750mm (29.5”) in height and 270mm (11") in diameter. The bollard boasts an IP68 rating which means that it is fully operational even when submerged in water. This semi-automatic bollard boasts a stainless steel coating to prevent corrosion, and also comes with optional LED lights for maximum visibility. An excavation depth of 1,750 mm (69”) is required when installing the BLG-04-SA bollard.

OR

Product
BLG-04-SA
Height (H)
750mm/29.5"
Foundation Depth
1750mm/ 68.9"
Internal Casing (I)
1590mm/ 62.5"
Internal Overlap (O)
600mm/ 16"
Dimeter (D)
270mm/ 11"
Options
Led lights, Stainless Steel
Crash Rating
ASTM F2656 07-M40-P1-Zero penetration 6.8 ton/ 65kph/ 13,600lbs/40mph
