METIS
SURFACE / SHALLOW MOUNT SLIDING BOLLARDS (M30/K4)
METIS is an innovative all-electric, plug-and-play bollards system, comprising of a pair of fixed bollards and a pair of sliding bollards, designed to meet the high-security needs of perimiter security, and the urban design needs of pedestrian streets. The METIS is placed on top of a concrete pad for a shallow-mount or surface-mount application, providing an advanced and reliable security and access control solution, which blends with its enviroment.
OR
Feature | BLG-METIS |
|---|---|
Height | 39.76"/1010mm |
Foundation Depth | 4.48"/114mm |
Normal Operating Speed | 4 Seconds |
IP Rating | IP-54 |
Crash Rating | IWA 14-1:2013
V/7200[N2A]/48/90:0.0 |
Operating Temperature | -20+60 C/ -4 +140 F (Optional Heating unit) |
Finish | Powder coating any RAL color. |
Features | Built-in IR safety sensors, RED/Green traffic light |
Actuator | Electric (3 phase motor with chain drive system) |
Sensors | Open/Closed limit switches |
Power | 1.5 Kw 3-phase motor running from a single-phase power supply |
Cycles per Day | 1500 |
MCBF | 1,500,000 cycles |
HIGHLIGHTS Elegant Look with high visibility red/green LED lights • Self-contained electrical controls and drive system • Minimal Maintenance • Plug & Play single phase power supply • minimal Excavation. Simple surface mount installation • Weather resistant with heating and drainage options
PHOTOS
VIDEOS
