The BLG-04-SA (Semi Automatic) is a manually tactivated bollard with a K8/M40 crash rating. Bollard is operated by an hydraulic piston. The bollard is pumped to an upper position using a handle, and retracted using a key, by sheer gravity. Alongside its affordable price (purchase and operational price) and reliability, make an ideal solution for Urban Vehicular Access Control (pedestrian security) and high-security applications in places where the bollards are less frequently operated (for example, seasonlly closed pedestrian streets). The BLG-04-SA does not require any underground cabling is required which reduces installations costs and operational costs. BLG-04-SA measures 750mm (29.5”) in height and 270mm (11") in diameter. The bollard boasts an IP68 rating which means that it is fully operational even when submerged in water. This semi-automatic bollard boasts a stainless steel coating to prevent corrosion, and also comes with optional LED lights for maximum visibility. An excavation depth of 1,750 mm (69”) is required when installing the BLG-04-SA bollard.
Download product data sheetProduct | BLG-04-SA |
---|---|
Height (H) | 750mm/29.5" |
Foundation Depth | 1750mm/ 68.9" |
Internal Casing (I) | 1590mm/ 62.5" |
Internal Overlap (O) | 600mm/ 16" |
Dimeter (D) | 270mm/ 11" |
Crash Rating | ASTM F2656 07-M40-P1-Zero penetration |
6.8 ton/ 65kph/ 13,600lbs/40mph | |
Options | Led lights, Stainless Steel |
